Description
The Jacketed Kettle is a cornerstone of industrial food processing, engineered for atmospheric cooking and mixing of diverse products like tomato purée, sauces, ragout, and dressings. Utilizing a vertical vessel design, the machine employs steam-based indirect heating to ensure uniform temperature distribution. To maintain product integrity and prevent scorching, it features integrated scraping paddles that continuously clear the bottom surface.
Usage
Uniform Heating: By circulating steam in a double-walled jacket, the vessel heats from all sides rather than just the bottom. This ensures consistent results across the entire batch.
Precise Temperature Control: Enable precise temperature control and cook food at the right temperature.
Reduced Cooking Times: Steam jacketed kettles have a heat surface area 3 to 4 times larger than stockpots, allowing them to reach boiling points faster.
Labour Savings: Integrated stirring and scraping paddles eliminate the need for constant manual monitoring.
Multifunctionality: High-end models can perform up to four processes: mixing, cooking, mashing, and chilling in a single unit.
Ease of Discharge: Tilting mechanisms up to 90 degrees allow for safe and effortless pouring of viscous or chunky products without the heavy lifting required for stockpots.
The Jacketed Kettle with Stirrer uses steam-based indirect heating through a double-walled jacket to cook gravies, sauces, sweets (mithai) and liquid items, with integrated scraping paddles to help prevent scorching. It has a heat surface area the page describes as 3 to 4 times larger than a stockpot, tilts up to 90 degrees for discharging viscous or chunky products, sits on wheels, and comes in 80 to 400 litre sizes with a 5-year warranty.
Specification table
| Specification | Detail |
| General Use | Mixing, boiling, roasting with inbuilt stirrer; cook gravies, sauces, sweets (mithai), liquid items |
| Power | 1 Horsepower (HP) |
| Capacity | 80 to 400 litres |
| Bowl diameter | 30 inch (80 litre model) |
| Movable | With wheels |
| Material | Stainless Steel |
| Weight (80 litre model) | 300 kg |
| Dimensions (80 litre model) | 80 x 90 x 100 cm |
| Warranty | 5 years |
Australia and New Zealand enquiries
Enquiries welcome from Sydney, Melbourne, Brisbane, Perth, Adelaide, Canberra, Central Coast, Newcastle, Wollongong, Gold Coast, Sunshine Coast, Truganina, Parramatta, Geelong, Hobart, Cairns, Townsville and Auckland, New Zealand.
FAQ
What sizes does the jacketed kettle come in?
80 to 400 litres.
What can I cook in it?
Gravies, sauces, sweets and liquid items, with indirect steam heating and integrated stirring.
